Concrete walls and deep beams are common load-bearing elements in building structures. However, due to the layout requirements, these bearing structures are very often weakened by doors, windows, and other openings.
The aim of the webinar is to present how to code-check a general-shape deep beam in IDEA StatiCa Detail in connection with results from the FEA application in minutes. We will show the workflow on an example of a residential concrete building – exporting the geometry, creating the submodel in IDEA StatiCa Detail, applying the correct loads, design of the reinforcement, and the final code-check for both ultimate and serviceability limit states.
Try it on your own - get the free Trial license and follow the step-by-step tutorial on Concrete wall.
Common 3D FEA software considers the linear behavior of concrete. Design and code-checks of reinforcement are limited, especially for the serviceability limit state which may lead to the development of excessive cracks. All of that is covered within the CSFM-based application IDEA StatiCa Detail. Now, all engineers can efficiently design and code-check walls or deep beams of any shape and many more.
If you want to see more of IDEA StatiCa Detail in action, there are two other recorded webinars to watch:
Or browse our Support center for tutorials and read the theoretical background.
